Aluminium Table Oval Screen Printing Machine better than M&R

FOB Reference Price:Get Latest Price
US $500-80,000 / Sets | 1 Set/Sets Aluminium Table Oval Screen Printing Machine better than M&R (Min. Order)
Contact Supplier Start Order
Loading...
Report Suspicious Activity
Overview
Product Hightlights
Color & Page Certification Gross Power
Multicolor CE Certification 60W
Specifications
Usage:
Cloths Printer, Label Printer, Cloth Printer; Label Printer
Plate Type:
Screen Printer
Condition:
New
Place of Origin:
Shandong, China (Mainland)
Brand Name:
YOUCHENG
Model Number:
YC-OPT0626
Automatic Grade:
Automatic
Voltage:
380V
Dimensions(L*W*H):
12mx4.2mx1.3m
Weight:
4000kgs
Name:
Aluminium Table Oval Screen Printing Machine better than M&R
Printing Speed:
500pcs-1200pcs/hour
Printing Precision:
+-0.01mm
Printing size:
Max 900x1100mm
Flash Dryer:
6 sets
Cooler:
6 sets
Touch Screen Could be Rorary:
yes
Platen quantity:
24 pcs
Platen material:
Aluminum alloy
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
One Year
Supply Ability
Supply Ability:
10 Set/Sets per Month Aluminium Table Oval Screen Printing Machine better than M&R
Packaging & Delivery
Packaging Details
Packed by Wooden Case for Aluminium Table Oval Screen Printing Machine better than M&R
Port
Yantai; Qingdao
Lead Time :
Shipped in 25 days after payment

Aluminium Table Oval Screen Printing Machine better than M&R



Application

It's suitable for printing t shirt ,garment,textile,bed sheet, baby clothes,underwear, swimwear,non-woven fabric,leather,pvc film etc.











Advantage:



1.)When the oval printing machine start work,the printing head is still, only the platen rotary so the speed is fast also the high precision and the error is no more than 0.01mm.

  2.)The important is that the space between the panels is big enough for the person could enter into the distance between the panles to put the textile,so more suitable for large size home textile printing.And the panel size could reach to 80cmx120cm.

  3.)The orbit adpoted TaiWan linear guideway,this type linear guideway with high precision and wear-resisting.

  4.)The chain has elastic function and could use 5 years.

  5.)The ends of the 4 annular oval automatic screen printing machine has two stations(panels),this could be realize one person to put or take out the textile.

  6.)The new developed oval screen printing machine could be foreward and inversion.

  7.)The touch screen could be rotary.




Parameters

                  Parameters of oval screen printng machine series
Name6 color 18 stations6 color 22 stations6 color 26 stations
ModelYC-OPT0618YC-OPT0622YC-OPT0626
Length8m10m12m
Width4.2m4.2m4.2m
Height1.3m1.3m1.3m
Printing Heads6 colors6 colors6 colors

Panel Size

600x800mm600x800mm

600x800mm

Printing size500x700mm500x700mm500x700mm
Panel Quantity18pcs22pcs26pcs
Flash dryer Power380v 12kw380v 12kw380v 12kw
Drying Size500x700mm500x700mm500x700mm
Flash dryer2 sets6 sets

6 sets

Coolernot includednot included

6 sets

Total Power380v 20kw380v 58kw380v 60kw
Weight3500kg3700kg4000kg
                                     Accessories and Origin
Printing Motor200W, Germany JSCC200W, Germany JSCC200W, Germany JSCC
PLCTaiwan , DeltaTaiwan, DeltaTaiwan, Delta
Touch Screen ComputerShenZhen, WeinviewShenZhen, WeinviewShenZhen, Weinview
Servo MotorShenzhen ONK 2.5KWShenzhen ONK 2.5KWShenzhen ONK 3.5KW
Printing air cylinderindependent research and developmentindependent research and developmentindependent research and development
OrbitalTaiwan cone shape orbitalTaiwan cone shape orbitalTaiwan cone shape orbital
BearingHarbinHarbinHarbin
Frenquency converterShenzhen ADTShenzhen ADTShenzhen ADT
Printed Samples










Our Services



1: Warranty 1 year, if any part is broken within 1 year, we will send a free replacement for you,while the dispatched charges is borned by buyer.



2: Our engineers will be to your company to install the machine and give the trainning about how to use and maintain the machine.



3: Any problem , you would get our answer at the first time , no later than within 2 hours.  We will try our best to solve the problem via email or teleconference.



4: We will give the best price to our agent , if you wanna to be our agent and cooperation in the long run, we will surely give you the best price with technology support.



Certifications







Packaging & Shipping







Company Information





FAQ



1. Q: We are interested in the screen printing machine,Could you quote the latest price to us?

A: In order to recommend the suitable machine for you ,please provide following information before we quote price:



    1.How many color to print will you need?

    2.What's your  max printing  size? (Such as 600x800mm or biger or smaller)

   3.What's the capacity per hour you request? (Such as 900pcs/h or more)

2. Q: What certificate do you have?

A: CE certificate.

3. Q: How does your factory do regarding quality control?

A: We have a special QC department in charge of products’ quality.

4.Q: How’s your ability to do independent research and development?

A: We have our own R&D department, South Korea tech,patent gotten.

5. Q: How long is the warranty period?

A: One year warranty.

6. Q: How much production capacity of your company per month?

A: 10 sets large fully automatic printing machines .

7. Q: Where is your factory located? How can we visit there?

A: Our head office  is located in Yantai City, Shandong; branch -office is in Liaocheng city, Shandong , China; and we have overseas office is in Ho Chi Minh City, Viet Nam.

8.Q: Which countries have you exported?

A:Netherlands, Poland, Russia , Japan , Korea,  India, Indonesia, Thailand, Vietnam, Cambodia , Uzbekistan, Belgium, Italy, Turkey, South Africa, UAE and so on.



Contact Information

Alison Jiang
Mobile/ whatsapp: +86 15066387918
Skype: iceberg8801
Company Information

    YANTAI YOUCHENG PRINTIING FACILITIES CO.,LTD   was founded in 2002 as the international manufacturer of screenprinting machine,dryer,stretching machine etc.We are a China-Korea jointed venture , our printing machines are made in China-Korea, core technology is introduced frm Korea, printing precision is very high , error is no more than 0.01mm .Youcheng are always being popular among the customers  for its superiaor quality and full after-sale service.Youcheng continue to improve our standard of customers and technology. Welcome to contact us for further information.
